Industrial 380V Three Phase VFD Inverter 18KW-90KW Open Loop Vector Control Inverter

Model Number : NVF2G-18KW/PS4

Brand Name : CHINT

Place of Origin : Zhejiang, China

Certification : CE

MOQ : 1 set

Price : $374-411 / set

Nominal Voltage : AC380V 440V

Power Phase Number : 3

Rated Power : 1.5KW~315KW(2.01hp~422.42hp)

Size : 1.5KW~315KW, 215*426*213mm

Type : VFD

Product name : VFD

Number of poles : 3 phase

Package : Carton

Brand : CHINT

Voltage classes : AC380V 440V

Rated current : 1.5~315KW

Rated frequency : 50/60HZ

Temperature : -35℃~70℃

Elevation of the installation site : ≤2000 m

Warranty : 3 months ~ 1 year

Customized : No

Contact Now

Product Overview

The NVF2G Series is a high-performance, open-loop vector control inverter designed for heavy-duty industrial applications. Engineered to provide precise speed regulation and high torque at low frequencies, the NVF2G is the go-to solution for large-scale motor control. Whether you are managing high-inertia loads like crushers or variable-torque applications like massive industrial fans, this VFD delivers the stability and efficiency required for modern smart factories.

Supporting a power range from 18.5kW to 315kW, the NVF2G series is built with an industrial-strength architecture. It integrates advanced protection algorithms and multi-function control logic to ensure your high-power motors operate smoothly under fluctuating load conditions.


Key Technical Advantages
  • High Starting Torque: Features advanced sensorless vector control (SVC) that provides 150% rated torque at 0.5Hz. This ensures reliable startups for heavy machinery under full load without stalling.

  • Intelligent Speed Regulation: Offers high-precision speed control with a regulation range of 1:100 (SVC), making it suitable for applications requiring strict speed consistency.

  • Dynamic Braking & Rapid Response: Optimized for fast-response environments. The drive manages rapid acceleration and deceleration cycles efficiently, preventing over-voltage trips during high-inertia braking.

  • Grid Adaptability: Designed with a wide voltage input range (380V ±15%) and enhanced anti-interference capabilities (EMC), ensuring stable performance even in areas with unstable power grids.

  • Multi-Stage Protection Suite: Comprehensive safeguarding including Over-current, Over-voltage, Phase Loss, Overload, Short-circuit, and Over-temperature protection for both the drive and the high-value motor.


Technical Specifications
Feature Detailed Specifications
Model Number NVF2G Series (High Performance)
Input Voltage 3-Phase AC 380V - 440V (50/60Hz)
Power Capacity 18.5kW, 22kW, 30kW, 45kW, 55kW, 75kW... up to 315kW
Control Mode Open-loop Vector Control (SVC), V/F Control
Output Frequency 0.00Hz - 400.00Hz
Overload Capacity 150% Rated Current for 60s | 180% for 3s
Cooling System Forced Air Cooling with Intelligent Fan Control
Communication Standard RS485 (Modbus RTU)
Standard Compliance IEC/EN 61800-3, CE Certified

Primary Application Scenarios
  1. Mining & Quarrying: Powering heavy-duty crushers, ball mills, and long-distance conveyor belts where high starting torque is non-negotiable.

  2. Water & Wastewater: Precision control for high-capacity centrifugal pumps and treatment plant aeration fans.

  3. Chemical & Processing: Maintaining constant pressure and speed for large mixers, extruders, and industrial reactors.

  4. Metal Fabrication: Speed control for high-power rolling mills, wire drawing machines, and industrial air compressors.


Why Engineers Specify the NVF2G Series?
  • User-Centric Design: Features a detachable LCD/LED keypad with a parameter copy function, allowing for rapid commissioning of multiple high-power drives across a facility.

  • Thermal Reliability: Equipped with high-performance IGBT modules and an optimized cooling channel design to prevent heat buildup during 24/7 continuous operation.

  • Flexible I/O Connectivity: Includes 6 digital inputs, 2 analog inputs, and programmable relay outputs, making it easy to interface with any PLC or SCADA architecture.

  • Ease of Maintenance: The modular internal structure and accessible terminals allow for quick inspections and cable connections, reducing downtime during routine maintenance.


Specification
Product name VFD
Place of origin Zhejiang,China

Product Images

FAQ

Q: Can this drive be used for 45kW fan and pump applications?

A: Yes. The NVF2G is a "General Purpose" drive with high overload capacity. While it is built for "Heavy Duty" (G-type) loads, it performs exceptionally well in energy-saving modes for fans and pumps.

Q: Does it support remote monitoring?

A: Absolutely. With the integrated Modbus RS485 interface, you can monitor frequency, current, and fault codes remotely from a control room HMI.

Q: Is it suitable for high-altitude installations?

A: The NVF2G can operate at high altitudes, though derating is required above 1000m. Please consult our technical manual for specific derating curves.

Q1: Are you trading company or manufacturer?

A1: We are manufacturer.

Q2: Do you have your own R&D team?

A2: Yes, we can customize products as your requirements.

Q3: How about the quality?

A3: We have the best professional engineer and strict QA and QC system.

Q4: Can we be your distributor?

A4: We are looking for distributor and agent all over the world.

Q5: How’s the package?

A5: Normally are wooden case, but also we can pack it according to your requirements.

Q6: How’s the delivery time?

A6: It depends on the quantity you need.
